GPS Receiver Electronic PCBA Circuit Boards Manufacturer

Product Categories

DQS Electronic Co., Limited

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

MOQ : 1

Price : Inquiry Us

Payment Terms : T/T

Layer : 8 Layer

Base Material : FR4

Min. Component Size : 0201

PCB Thickness : 1.5mm

Pin Space : 0.1mm

Surface Finish : Immersion Gold

Testing Method : Flying Probe, ICT, Functional Test,AOI

Application : GPS Receiver

Contact Now

GPS Receiver Electronic PCBA Circuit Boards Manufacturer

♦ What is electronic PCBA?

- PCBA stands for Printed Circuit Board Assembly.
  It is the PCB after all the electronic components have been soldered onto it; in other words, it is the finished, functioning circuit board that can be installed into a product.

♦ DQS's PCB Assembly Capability

Item				Normal	Special
SMT Assembly	PCB(used for SMT) specification	Length and Width( L* W)	Minimum	L≥3mm, W≥3mm	L＜2mm
		Length and Width( L* W)	Maximum	L≤800mm, W≤460mm	L ＞ 1200mm, W＞500mm
		Thickness( T)	Thinnest	0.2mm	T＜0.1mm
		Thickness( T)	Thickest	4 mm	T＞4.5mm
	SMT components specification	Outline Dimension	Min size	0201(0.6mm*0.3mm)	01005(0.3mm*0.2mm)
			Max size	200 * 125	200 * 125
			component thickness	T≤15mm	6.5mm＜T≤15mm
		QFP,SOP,SOJ (multi pins)	Min pin space	0.4mm	0.3mm≤Pitch＜0.4mm
		CSP/ BGA	Min ball space	0.5mm	0.3mm≤Pitch＜0.5mm
DIP Assembly	PCB specification	Length and Width( L* W)	Minimum	L≥50mm, W≥30mm	L＜50mm
		Length and Width( L* W)	Maximum	L≤1200mm, W≤450mm	L≥1200mm, W≥500mm
		Thickness( T)	Thinnest	0.8mm	T＜0.8mm
		Thickness( T)	Thickest	3.5mm	T＞2mm

♦ One-Stop Electronic Manufacturing Including

♦ Core Competencies of DQS PCB Assembly

SMT		DIP
13 automatic high-speed SMT line 5 million points / day FPC/Double sided mounted Automatic conformal coating		4 DIP line Post-soldering700,000 points/day Professional DIP plug-in team
	SMT Technology		PCBA OEM
	Min package: 01005 Min pin: 0.3mm Min BGA pitch: 0.3 mm		Full turnkey PCB assembly Partial turnkey PCB assembly
